Hybrid


TEK and timber frame components can be combined with the following materials to create hybrid/bespoke buildings to suit your budget and specification requirements.

INTERNAL WALL PANELS

Typically 38mm x 89mm or 38 x 140mm untreated timber frame panels.


FLOOR JOIST SYSTEMS

Masonite engineered I-Joist floor systems
200mm, 240mm, 300mm, 350mm, 400mm, 450mm

Posi-Joist (open metal web joists)
202mm, 225mm, 253mm, 304mm


STRUCTURAL DECKING

22mm 2400 x 600mm Egger Protect (or similarly approved)
15 mm OSB3 Subdeck floors
18 mm OSB3 flat roof deck


ROOF FRAMING (NON SIPS)

Roof Trusses
Alternatively Masonite or Posi-Joist systems can be used to form long span rafters


STRUCTURAL SUPPORT BEAMS

European whitewood Glulam structural beams
Widths: 45mm, 90mm, 115mm, 140mm, 200mm
Depths: 240mm, 270mm, 300mm, 315mm, 360mm, 405mm, 450mm, 495mm,
585mm, 630mm

Glulam Portal Frames (Straight)

Glulam Portal Frames (Curved)


MEMBRANES, TAPES, BARRIERS

Kingspan Nilvent (TEK roofs and ventilated cavity wall applications)
Reflective breather membrane (Closed masonry cavity)
Reflective vapour control layers
Polythene vapour control layers
Vapour permeable membranes are also available

We also supply the SIGA range of air tight tapes, membranes and barriers as required.


OTHER INSULATION MATERIALS

To suit project and specification; typically site fitted and positioned with battens. All joints taped using appropriate foil jointing materials.

Kingspan TW55 PIR rigid board - various thickness (wall upgrades)

Kingspan TP10 PIR rigid board - various thickness (roof upgrades)
